In-Depth Review Of E1 Charger In Malaysia

Thumbnail for E1 Charger Review
The E1 Charger – Full Review

Selecting an EV charger shouldn’t be trivial and, most importantly, easy for the end users. That’s where we jump in and make it easier for you to consider an EV charger that ticks all the boxes to pre-emptively get you up to speed with the basis of EV charging.

The Charger in Question – E1 Charger, An Overview

The E1 Charger comes with a 5m cable tethered
The E1 Charger- All you would need from an EV Charger

The design and material of the E1 Charger

The EV Charger is encased in a black thermoplastic shell, effortlessly blending in in whichever installation point setting the user chooses. Although plastic, it is strong enough to withstand a 1m drop while remaining functional. The EV charger also houses a small LCD screen for users to have a better understanding of the charging process as well as denote any error if it ever occurs. The E1 Charger also comes with 1-year warranty pledge.

Compatibility Wise – E1 Charger

The E1 Charger has a permanently attached TYPE 2 connector that makes it vastly compatible with almost any choice of electric vehicle in Malaysia. An added plus is that, the cable itself is affixed to the shell of the EV Charger ,so you don’t have to worry about losing it by misplacing

Performance specification of the E1

The charger can be installed and is configurable for purchase at 7kW, 11kW, or 22kW. The wide range of power outputs available allows users to pick and choose their most favorable option to combine with their respective EVs. The E1 charger includes the ability to configure the amperage and kW of the charger itself, making it much more flexible for the charging curve intended by the end user. The following are the specifications of the charge output on the E1 chargers.

The E1 Charger affixed and mounted to a Wall with an isolator switch .
The E1 Charger’s wiring can be installed concealed instead of within a PVC
The E1 charger is purchasable to a range of 7kw to 22kW
The performance specification table for the E1 charger

Installation point and dimensions

The E1 charger is configurable for mounting on a wall and affixed to a pedestal as an add on option. Furthermore, due to its small form factor and dimensions, it can be used for most installation placements within the outer walls of your home. Included with the E1 charger itself is a permanently installed plug-in cable that is by default up to 5 meters in length, which grants great maneuverability to whichever position you may find your EV in whilst parked to charge. However, Energielite also provides longer cables of up to 10 meters at an extra cost if you find it insufficient.

The smart features of the E1 Charger

The black thermoplastic adds to overall sheen of an EV charger, functionality with aesthetics.
Face front of the E1 Charger that has multiple functions embedded including a LCD screen display

Not only does the E1 excel in its range of specifications for performance, but it also grants extra features that help elevate the charging process experience, which are:

App control—The E1 Charger has Wi-Fi capabilities, which translate to application usage, allowing you to monitor and control the charging process.

Screen display—The LCD display screen allows information to be displayed while charging and easier to navigate as there is visual feedback.

RFID Card Reader—You can quickly tap the configured charging settings saved onto the RFID, perfect for charging different EVs.

Current and Appointment settings button—These buttons allow you to change the current supply to the EV and the period for which you would like the vehicle to charge, such as 30 minutes—1 hour, etc.

The safety features of the E1 Charger

Ultimately, what’s most important is that you can charge safely without worrying about the possibility of your EV or charger combusting into flames. There are a few safety features that you’d want embedded into your EV charger that would allow effortless charging. Thankfully, the E1 charger accounts for all of this and implements them to safeguard your charging experience.

Ground Fault protection – isolating shock hazards from the user

Short circuit protection – Abnormal flow of current will be detected, and proactive measures of interrupting the flow of electricity prevent further damage or danger to user and property.

Temperature monitoring ­– Reducing the output power accordingly to ensure that the charger doesn’t overheat during operation.

IP65 protection level—The E1 Charger is considered an outdoor installation, so it is highly resistant to dust and can withstand low-pressure water jets from all directions.

Price of the E1 Charger

Unlike most chargers on the market, the E1 Charger doesn’t put a hole in your wallets. Instead, it offers a premium feature at a non-premium price that would compel those who seek value in their purchases. I’m pretty sure you’d want to save more rather than spend it all on gimmicks that don’t even share the same sentiment as owning an EV in the first place , savings!

Energielite- The only EV Charger installer you’ll need

We’ve done hundreds of installations in the span of 2 years that we’ve provided our services to Malaysians and that also includes the E1 Charger. Trust in our services as our customer’s have, with the highest ratings in EV charger installations under Google reviews, we’re confident in the workmanship we provide, and it can only get better with each installation we complete. Own a different brand of EV charger but don’t know who to properly install it, allow us the pleasure of making it one less of a problem to think of!

Installations services can be provided with the purchase of our EV chargers or if you need just the service of installation if you already own one.
Installations done for E1 Charger has been plenty, and we’ve done for many other brands as well!
